APPLICATION STANDARDS:
1. Design and manufacture according to: API6D, API594, ASME B16.34
2. Connection flange dimension according to ANSI B16.5, ANSI B16.47;
3. Test and inspection according to: API 598.
4. Structure features: Double-plate wafer check valve
5. Material conform to : ANSI/ASTM
6. Main Material: WCB, CF8M, CF3M, CN7M, CW12MW, CW6MC, CY40, CR20, etc.
The wafer check valve CF8M small size is designed for high-purity applications in food, pharmaceutical, and chemical industries. Made from CF8M (316L) stainless steel, it resists corrosion from acids, chlorides, and other aggressive fluids. Its compact wafer design installs easily between flanges, saving space in tight systems. The spring-loaded disc ensures fast closure to prevent backflow and water hammer. Rated for low to medium pressure systems, it meets ASME B16.34 standards and is API 598 tested. Ideal for clean-in-place (CIP) and sterile processes, this wafer check valve CF8M small size delivers reliable, hygienic performance. Trust SFANVALVE for valves built to meet strict industry requirements.
| Brand | SFAN VALVE OR "OEM" |
|---|---|
| Flow bore | Standard bore |
| Material | Carbon steel, Stainless steel, Alloy steel or other |
| Dimension | DN50(2") to DN1200(48") |
| Class | 150~2500 |
| Medium | Water, oil &gas. |
| Temperature | -196℃(cryogenic design) to 700℃ |
| Valve test | 100% quantity tested before delivery |
| Valve guarantee | 18 months after shipments and 12 months after installed |
| Packing | Plywood or carton cases |
| Delivery time | 7 days to 30 days |
| Place of Origin | Zhejiang, China |


| NO. | Part name | C.S. | C.S. | C.S. | L.T.C.S. | L.T.C.S. | L.T.C.S. | L.T.C.S. | S.S. | S.S. | S.S. | S.S. | D.S.S. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Body | A216 WCB+304 | A216 WCB+316 | A216 WCB+13CR | A352 LCB+304 | A216 WCB+316 | A352 LCC+304 | A216 WCB+316 | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M | A890 4A |
| 2 | Disc | A351 CF8 | A351 CF8M | A217 Ca15 | A351 CF8 | A351 CF8M | A351 CF8 | A351 CF8M | A351 CF8 | A351 CF8M | A351 CF3 | A351 CF3M | A890 4A |
| 3 | Pin | A182 F304 | A182 F316 | A182 F6 | A182 F304 | A182 F316 | A182 F304 | A182 F316 | A182 F304 | A182 F316 | A182 F304L | A182 F316L | A182 F51 |
| 4 | Pin retainer | C.S | C.S | C.S | C.S | C.S | C.S | C.S | SS304 | SS316 | SS304L | SS316L | UNS S31803 |
| 5 | Plate | C.S | C.S | C.S | C.S | C.S | C.S | C.S | SS304 | SS316 | SS304L | SS316L | UNS S31803 |
| 6 | Eyebolt | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn | AISI 1035+Zn |
| 7 | Screw | AISI 1025 | AISI 1025 | AISI 1025 | AISI 1025 | AISI 1025 | AISI 1025 | AISI 1025 | S.S | S.S | S.S | S.S | S.S |
| 8 | Axle bushing | SS304 | SS316 | A276 T410 | SS304 | SS316 | SS304 | SS316 | SS304 | SS316 | SS304 | SS316 | SS316 |
| 9 | Spring | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 | Inconel X750 |
| Application | Application service | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. | Oil, gas, water etc. |
| Application | App.temp.(℃) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤425℃(Metal-to-metal seated) | ≤150℃(Viton seated ) | ≤150℃(Viton seated ) | ≤150℃(Viton seated ) | ≤150℃(Viton seated ) | ≤150℃(Viton seated ) |
| Design & Manufacture | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | API594, API6D, ASME B16.34 | |
| Face-to-face(Length) | API594 | API594 | API594 | API594 | API594 | API594 | API594 | API594 | API594 | API594 | API594 | API594 | |
| Connection | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | ANSI B16.5(Size≤24"), ANSI B16.47A(MSS SP-44)/ANSI B16.47B(API605)(26"≤Size≤60"), AWWA C207 Class D, AWWA C207 Class E; | |
| Pressure test | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | API598, ISO 5208 | |
| Remark | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements | Seat surface and disc surface can be hard faced with Stellite according to client's requirements |
Your questions answered
For Sfanvalve’s standard products, we are willing to start production without any payment in advance. We accept product inspection upon completion, and payment is only due once the inspection is passed. SFAN will then arrange shipment to your designated warehouse as per your requirements.
Yes. After receiving the contract, we will provide technical drawings. Production will commence based on these drawings once they are confirmed by both parties.
After receiving the contract and confirming the drawings, we will provide a production schedule and manufacture strictly according to it. We will provide photos or videos to share and make a record for every stage of the production process. If a serious delay occurs due to management error, we will arrange air shipment and bear all costs by air.”
The warranty period is 18 months from the date of shipment or 12 months from the date of installation, whichever occurs first.
