1. Design and manufacture according to: API 6D, BS 5351;
2. Connection flange ends according to: ANSI B16.5;
3. Test and inspection according to: API 598.
4. Structure features: floating ball;
5. Material conform to : ANSI/ASTM
6. Main Material: A105(N), LF2, F304(L), F316(L), F51, F91, F11, F22, F321, etc.
The floating ball valve is built for extreme conditions using ASTM A182 F53 super duplex stainless steel, offering unmatched resistance to chloride corrosion and stress cracking. Rated at 600LB, it handles high-pressure service in offshore oil & gas, chemical, and desalination plants. Its one-side flange and butt weld end design allows flexible pipeline integration. The floating ball mechanism ensures reliable, bubble-tight shut-off under pressure. Compliant with API 607 and 100% tested per API 598, this valve delivers long-term performance in aggressive media. Trust SFANVALVE for precision-engineered floating ball valves that outperform standard materials in harsh environments.
| Brand | SFAN VALVE OR "OEM" |
|---|---|
| Flow bore | Standard bore or Full bore |
| Material | Carbon steel, Stainless steel, Alloy steel or other |
| Dimension | DN10(1/4") to DN100(4") |
| Class | 150~2500 |
| Medium | Water, oil &gas. |
| Temperature | -196℃(cryogenic design) to 560℃ |
| Valve test | 100% quantity tested before delivery |
| Valve guarantee | 18 months after shipments and 12 months after installed |
| Packing | Plywood or carton cases |
| Delivery time | 7 days to 30 days |
| Place of Origin | Zhejiang, China |
Your questions answered
For Sfanvalve’s standard products, we are willing to start production without any payment in advance. We accept product inspection upon completion, and payment is only due once the inspection is passed. SFAN will then arrange shipment to your designated warehouse as per your requirements.
Yes. After receiving the contract, we will provide technical drawings. Production will commence based on these drawings once they are confirmed by both parties.
After receiving the contract and confirming the drawings, we will provide a production schedule and manufacture strictly according to it. We will provide photos or videos to share and make a record for every stage of the production process. If a serious delay occurs due to management error, we will arrange air shipment and bear all costs by air.”
The warranty period is 18 months from the date of shipment or 12 months from the date of installation, whichever occurs first.
